Webp not work in Browser

Please fill in any relevant information that applies to you:

• CentOS Version: AlmaLinux 9.5

• Centmin Mod Version Installed:140.00beta01.b171

• Nginx Version Installed: 1.27.3 ?

• PHP Version Installed: 8.2.26
• Persistent Config:
• Code:

  SET_DEFAULT_MYSQLCHARSET='utf8mb4'
  SELFSIGNEDSSL_ECDSA='y'
  PHPFINFO='y'
  PHP_OVERWRITECONF='n'
  PYTHON_INSTALL_ALTERNATIVES='y'
  MARCH_TARGETNATIVE='n'
  NGINX_ONETWOTHREE_COMPAT='y'
  GENERAL_DEVTOOLSETGCC='y'
  DEVTOOLSETTEN='n'
  DEVTOOLSETELEVEN='n'
  DEVTOOLSETTWELVE='y'
  SELFSIGNEDSSL_ECDSA='y'
  PHP_PGO_ALWAYS='y'
  PHP_PGO='y'
  PHPFINFO='y'
  PHP_OVERWRITECONF='n'
  PYTHON_INSTALL_ALTERNATIVES='y'
  DMOTD_PHPCHECK='y'
  NGINX_GEOIPTWOLITE='y'
  NGXDYNAMIC_GEOIPTWOLITE='y'
  NGINX_HPACK='y'
  NGINX_DYNAMICTLS='y'
  NGINX_PCRE_TWO='y'
  OPENSSL_VERSION='3.1.4'
  OPENSSL_VERSIONFALLBACK='3.1.4'
  OPENSSL_VERSION_OLDOVERRIDE='3.1.4'
  NGINX_NJS='y'
  NGXDYNAMIC_NJS='y'
  NGXDYNAMIC_BROTLI='y'
  NGINX_LIBBROTLI='y'
  NGINX_VIDEO='y'
  #ENABLE_MARIADBTENFOURUPGRADE='y'
  #ENABLE_MARIADBTENFIVEUPGRADE='y'
  ENABLE_MARIADBTENSIXUPGRADE='y'
  LETSENCRYPT_DETECT='y'
  ACME_DEFAULT_CA='zerossl'
  MARCH_TARGETNATIVE='n'
  AUTODETECPHP_OVERRIDE='y'


• DNS over cloudflare no proxy

I had to change my VPS from inceptionhosting to clouvider and restore the Wordpress site backup.

but webp config not work

Code:

# webp extension support if you are converting /uploads images to webp
 location ~ ^/wp-content/uploads/ {
   location ~* ^/wp-content/uploads/(.+/)?(.+)\.(png|jpe?g)$ {
   expires 30d;
   add_header Vary "Accept";
   add_header Cache-Control "public, no-transform";
   try_files $uri$webp_extension $uri =404;
  }
}

Webp files are generat generated with webp-optimize

Code:

0 */1 * * * /root/tools/optimise-images/optimise-images.sh optimise-cron-age  /home/nginx/domains/mojobus.org/public/wp-content/uploads/ >/dev/null 2>&1

everything worked on the old VPS

or is there a better way to deliver webp now
Any Tip
Thanks

---



.webp images is created
https://mojobus.org/wp-content/uploads/v2-bfw0t-jsqcp-e1716464553299.jpg.webp
but not being served to visitors

Code:

# Centmin Mod Getting Started Guide
# must read https://centminmod.com/getstarted.html
# For HTTP/2 SSL Setup
# read https://centminmod.com/letsencrypt-freessl.html

# redirect from www to non-www  forced SSL
# uncomment, save file and restart Nginx to enable
# if unsure use return 302 before using return 301
# server {
#   server_name mojobus.org www.mojobus.org;
#    return 302 https://$server_name$request_uri;
# }

server {
  listen 443 ssl http2;

  server_name mojobus.org www.mojobus.org;

  include /usr/local/nginx/conf/staticfiles.conf;
  include /usr/local/nginx/conf/ssl/mojobus.org/mojobus.org.crt.key.conf;
  include /usr/local/nginx/conf/ssl_include.conf;

  # cloudflare authenticated origin pull cert community.centminmod.com/threads/13847/
  #ssl_client_certificate /usr/local/nginx/conf/ssl/cloudflare/mojobus.org/origin.crt;
  #ssl_verify_client on;



  # mozilla recommended
  ssl_ciphers ECDHE-ECDSA-AES128-GCM-SHA256:ECDHE-RSA-AES128-GCM-SHA256:ECDHE-ECDSA-AES256-GCM-SHA384:ECDHE-RSA-AES256-GCM-SHA384:ECDHE-ECDSA-CHACHA20-POLY1305:ECDHE-RSA-CHACHA20-POLY1305:DHE-RSA-AES128-GCM-SHA256:DHE-RSA-AES256-GCM-SHA384;
  ssl_prefer_server_ciphers   on;
  #add_header Alternate-Protocol  443:npn-spdy/3;


  # before enabling HSTS line below read centminmod.com/nginx_domain_dns_setup.html#hsts
  #add_header Strict-Transport-Security "max-age=31536000; includeSubdomains;";
  #add_header X-Frame-Options SAMEORIGIN;
  add_header X-Xss-Protection "1; mode=block" always;
  add_header X-Content-Type-Options "nosniff" always;
  #add_header Referrer-Policy "strict-origin-when-cross-origin";
  #add_header Permissions-Policy "accelerometer=(), camera=(), geolocation=(), gyroscope=(), magnetometer=(), microphone=(), payment=(), usb=()";
  #spdy_headers_comp 5;
  ssl_buffer_size 1369;
  ssl_session_tickets on;

  # enable ocsp stapling
  resolver 8.8.8.8 8.8.4.4 1.1.1.1 1.0.0.1 valid=10m;
  resolver_timeout 10s;
  ssl_stapling on;
  ssl_stapling_verify on;

# ngx_pagespeed & ngx_pagespeed handler
#include /usr/local/nginx/conf/pagespeed.conf;
#include /usr/local/nginx/conf/pagespeedhandler.conf;
#include /usr/local/nginx/conf/pagespeedstatslog.conf;

  # limit_conn limit_per_ip 16;
  # ssi  on;

  access_log /home/nginx/domains/mojobus.org/log/access.log combined buffer=256k flush=5m;
  #access_log /home/nginx/domains/mojobus.org/log/access.json main_json buffer=256k flush=5m;
  error_log /home/nginx/domains/mojobus.org/log/error.log;

  include /usr/local/nginx/conf/autoprotect/mojobus.org/autoprotect-mojobus.org.conf;
  root /home/nginx/domains/mojobus.org/public;
  # uncomment cloudflare.conf include if using cloudflare for
  # server and/or vhost site
  include /usr/local/nginx/conf/cloudflare.conf;
  include /usr/local/nginx/conf/503include-main.conf;

  include /usr/local/nginx/conf/wpincludes/mojobus.org/wpcacheenabler_mojobus.org.conf;
  #include /usr/local/nginx/conf/wpincludes/mojobus.org/wpsupercache_mojobus.org.conf;
  # https://community.centminmod.com/posts/18828/
  #include /usr/local/nginx/conf/wpincludes/mojobus.org/rediscache_mojobus.org.conf;

  location / {
  include /usr/local/nginx/conf/503include-only.conf;


  # Enables directory listings when index file not found
  #autoindex  on;

  # for wordpress super cache plugin
  #try_files /wp-content/cache/supercache/$http_host/$cache_uri/index.html $uri $uri/ /index.php?q=$uri&$args;

  # for wp cache enabler plugin
  try_files $cache_enabler_uri_webp $cache_enabler_uri $uri $uri/ $custom_subdir/index.php?$args;

  # Wordpress Permalinks
  #try_files $uri $uri/ /index.php?q=$uri&$args;

  # Nginx level redis Wordpress
  # https://community.centminmod.com/posts/18828/
  #try_files $uri $uri/ /index.php?$args;

  }

location ~* /(wp-login\.php) {
    limit_req zone=xwplogin burst=1 nodelay;
    #limit_conn xwpconlimit 30;
    #auth_basic "Private";
    #auth_basic_user_file /home/nginx/domains/mojobus.org/htpasswd_wplogin;
    include /usr/local/nginx/conf/php-wpsc.conf;

    # https://community.centminmod.com/posts/18828/
    #include /usr/local/nginx/conf/php-rediscache.conf;
}

location ~* /(xmlrpc\.php) {
    limit_req zone=xwprpc burst=45 nodelay;
    #limit_conn xwpconlimit 30;
    include /usr/local/nginx/conf/php-wpsc.conf;
    # https://jetpack.com/support/how-to-add-jetpack-ips-allowlist/
    include /usr/local/nginx/conf/jetpack_whitelist_ip.conf;

    # https://community.centminmod.com/posts/18828/
    #include /usr/local/nginx/conf/php-rediscache.conf;
}

location ~* /wp-admin/(load-scripts\.php) {
    limit_req zone=xwprpc burst=5 nodelay;
    #limit_conn xwpconlimit 30;
    include /usr/local/nginx/conf/php-wpsc.conf;

    # https://community.centminmod.com/posts/18828/
    #include /usr/local/nginx/conf/php-rediscache.conf;
}

location ~* /wp-admin/(load-styles\.php) {
    limit_req zone=xwprpc burst=5 nodelay;
    #limit_conn xwpconlimit 30;
    include /usr/local/nginx/conf/php-wpsc.conf;

    # https://community.centminmod.com/posts/18828/
    #include /usr/local/nginx/conf/php-rediscache.conf;
}

#activpub
location ^~ /.well-known/webfinger {
  auth_basic off;
  allow all;
  default_type text/plain;
  try_files $uri $uri/ /index.php?$args;
  break;
}

#well-know nostr

location ^~ /.well-known/nostr.json {
     auth_basic off;
  allow all;
  default_type text/plain;
  try_files $uri $uri/ /index.php?$args;
  break;
}


#npub.pro support  Replace with the actual path to your Nostr-generated files
#location ^~ /abgefahren/ {
#    root /home/nginx/domains/mojobus.org/public/abgefahren;
#    index index.html;
#    try_files $uri index.html;
#}


# webp extension support if you are converting /uploads images to webp
 location ~ ^/wp-content/uploads/ {
   location ~* ^/wp-content/uploads/(.+/)?(.+)\.(png|jpe?g)$ {
   expires 30d;
   add_header Vary "Accept";
   add_header Cache-Control "public, no-transform";
   try_files $uri$webp_extension $uri =404;
  }
}


#Expires Header

location ~* \.(jpg|jpeg|gif|png|webp)$ {
   expires 365d;
}

location ~* \.(pdf|css|html|js|swf)$ {
   expires 2d;
}


  include /usr/local/nginx/conf/wpincludes/mojobus.org/wpsecure_mojobus.org.conf;
  include /usr/local/nginx/conf/php-wpsc.conf;

  # https://community.centminmod.com/posts/18828/
  #include /usr/local/nginx/conf/php-rediscache.conf;
  include /usr/local/nginx/conf/pre-staticfiles-local-mojobus.org.conf;
  include /usr/local/nginx/conf/pre-staticfiles-global.conf;
  include /usr/local/nginx/conf/staticfiles.conf;
  include /usr/local/nginx/conf/drop.conf;
  #include /usr/local/nginx/conf/errorpage.conf;
  include /usr/local/nginx/conf/vts_server.conf;
}



Hello,
Yes
/usr/local/nginx/conf/webp.conf

Code:

map $http_accept $webpok {
   default   0;
   "~*webp"  1;
}

map $http_cf_cache_status $iscf {
   default   1;
   ""        0;
}

map $webpok$iscf $webp_extension {
  11          "";
  10          ".webp";
  01          "";
  00          "";
}

nginx.conf

Code:

# integration in vhosts created by addons/acmetool.sh
more_set_headers "Server: nginx centminmod";
more_set_headers "X-Powered-By: centminmod";
#more_set_headers "Server: nginx";
#more_clear_headers "X-Powered-By";

# uncomment cloudflare.conf include if using cloudflare for
# server and/or vhost site + setup cron job for command
# /usr/local/src/centminmod/tools/csfcf.sh auto
# run the auto command once to populate cloudflare ips
#include /usr/local/nginx/conf/cloudflare.conf;
# uncomment incapsula.conf include if using incapsula for
# server and/or vhost site + setup cron job for command
# /usr/local/src/centminmod/tools/csfincapsula.sh auto
# run the auto command once to popular incapsula ips
#include /usr/local/nginx/conf/incapsula.conf;
include /usr/local/nginx/conf/maintenance.conf;
#include /usr/local/nginx/conf/vts_http.conf;
include /usr/local/nginx/conf/geoip.conf;
include /usr/local/nginx/conf/webp.conf;
include /usr/local/nginx/conf/ssl_include.conf;
#include /usr/local/nginx/conf/pagespeedadmin.conf;
include /usr/local/nginx/conf/fastcgi_param_https_map.conf;
include /usr/local/nginx/conf/redisupstream.conf;
include /usr/local/nginx/conf/wpcacheenabler_map.conf;
include /usr/local/nginx/conf/normalize_encoding.conf;
include /usr/local/nginx/conf/default_phpupstream.conf;
